Lower latency and higher throughput than any switched fabric.

Switch to

switch-less

networking.

A totally new and radically better approach for networking

All other network architectures are managed by a network control hierarchy. Lightfleet conceived and developed a network fabric, the Data Distribution System (DDS), where data transfers are self-directed, requiring no separate control plane to delay the data transfers.

Dramatically reducing latencies and increasing throughput. Learn more.

The architecture performs with far less software and complexity to delivery dramatically reduced latency and network congestion, especially for multicasting applications. The first generation Lightfleet products for top-of-rack use in HPC systems are available for evluation now, after exhibiting more than 30% lower latency and up to 7X higher throughput as confirmed by Tolly Enterprises.

Technology

Continuous Flow vs. Stop-and-Go
The Analogy

The Traffic Grid

The Round About

The Reality

Continuous Flow Distribution

Products

Certified Superior Performance

Lightfleet DDS
Data Distribution System

Stop cracking your knuckles. The nanosecond delays are over.

Lower latency, node-to-node, than the fastest switches.

More throughput, especially in congestion.

Far less power consumption, too.

24 Fixed Optical Fiber channel Ports

10 Gbs / Channel
24 TX 24 RX

Dual redundant, hot-swappable power supplies
Lightfleet HBA

The HBA is PCI Express compatible and uses the lightweight Lightfleet data format that enables data flow between servers without Ethernet overhead.

Specifications

Physical

  • 24 fixed fiber channel ports (10 Gbps)
  • Dual redundant, hot-swappable power supplies
  • LED link indicator

DDM Power

Power Supplies: 2 (redundant)
Power Supply Airflow: Rear airflow exhaust
Input Voltage: 100 to 240 VAC
Frequency: 47 to 63 Hz
Typical Operating Power: 82 W (24 ports at 100% load)
Maximum Power: 110 W

HBA Power

Typical Operating Power  15 W: 1 port active with SR optics at 100% load
Maximum power: 25 W
Input Voltage: 12 V from server

Regulatory Compliance

EMC FCC CFR 47 Part 15 Class A

Cooling

Front-to-back airflow: Port-side exhaust (air enters the front grill and exits through ports and power supplies)

Cabling

  • MTP/MPO connection
  • Multimode fIber (MMF OM3) to a distance of 328 ft (100 m)

Environment

DDM Dimensions (height x width x depth)
1.75 x 17.125 x 20 in.
(4.45 x 43.5 x 50.8 cm)
Weight (DDM):   20 lb   (9.0 kg)
Operating Temperature:  32 to 104°F (0 to 40°C)
Storage Temperature:     -40 to 158°F (-40 to 70°C)
Relative Humidity (Operating):   10 to 85% non-condensing
Relative Humidity (Non-operating):    5 to 95% non-condensing
Altitude:     0 to 10,000 ft  (0 to 3000m)

About LightFleet

Over 35 Patents

A technically diverse team

Lightfleet was founded in 2003 by a team of individuals seeking to deliver innovative computer hardware and associated software system products. The company’s staff has diverse backgrounds in optics, signal processing, neural computing, massively parallel processing and semiconductor design. The team is responsible for over 35 patents, either obtained or in process.
